Which consists of a small mass which is etched into silicon surface and then integrated into a small circuit. Some works on the principle of MEMS( micro electro mechanical sensor) working. Working Principle of ADXL 335 Accelerometer ¶Ĭurrently different types of accelerometers are available in market which are used for different purposes.
This pin provides analog input signal to controller which is measured by ADLX 335 accelerometer This is Z pin and is used for analog input in Z axis dimension. This is Y pin and is used for analog input in y axis dimension. This is X pin and is used for analog input in x axis dimension. This is ground pin and is used for supplying ground to this ADLX 335 accelerometer. It is connected with 3.3V dc power source This is VCC pin and is used for power on the ADLX 335 accelerometer. Its pin configuration is shown in below table and this ADXL 335 accelerometer is connected with any controller according to this table. Pin Configure of ADXL 335 Accelerometer ¶Įvery ADXL 335 accelerometer consists of five pins which are used for different purposes. It is easily available in market or online shop. It is mostly used in construction working machines such as drilling ,driving piles and demolition etc., human activities machines such running, walking, dancing and skipping etc. When it is used for acceleration measure purposes then it is interfaced with any type of controller such as microcontroller or Arduino etc.
It is low noise and less power consume device. It measures the acceleration in the form of analog inputs, in three dimension direction such as X,Y and Z. If we talk about ADXL 335 accelerometer, then this accelerometer is a device that is used for measuring acceleration of any object. Sometimes both are changed simultaneously.
There are two ways for explaining acceleration of anything first one is change in speed and second one is change in direction. Similarly, velocity is a speed and direction. What is Acceleration and ADXL 335 Accelerometer? Acceleration is a process in which velocity is changed with respect to time and it is a vector quantity.
